Jerrycar Bowser 630H
Jerrycar custom manufactures a wide variety of high-quality tailors at affordable prices. Each trailer comes with a fully equipped pump station including the pump, meter, filter and hose. Our customers also have the luxury of choosing the colour of their trailer (subject to availability).
Fuel Types – Diesel, Petrol, Avgas, Mogas, Paraffin and JetA1
Available sizes – 630L, 1100L, 1800L and 2200L
Specifications
| Specifications: Jerrycar model 630H – 600 litre tanker | |
| Chassis and suspension | |
| Structure and draw bar: | 100mm x 50mm x 3mm rectangular tubing |
| 2 x 5 blade spring 685mm: | Capacity 1300kg |
| U/Br axle 45mm 5/114: | Capacity 1300kg |
| Coupling device: | Trailer coupler clip-on |
| Rims 14″ tyres 195R14C: | (1700kg out rating on both tyres) |
| Paint: | Etch primer/stone chip all over/2K Top Cote |
| Vehicle dimensions | |
| Empty weight of vehicle: | 280kg |
| Width: | 1810mm |
| Height: | 1000mm (breather and cap excluded) |
| Height with breather: | 1370mm |
| Length with draw bar: | 2500mm |
| Draw bar length: | 1040mm |
| Track: | 1600mm |
| Tank | |
| Capacity: | 630 litre with breather – pressure tested at 50kpa |
| Wall thickness: | 2.5mm steel |
| Inlet: | 65mm adaptor with quick coupler cap |
| Outlet: | 25mm female at back of trailer |
| Paint: | Etch primer/stone chip all over/2K Top Cote |
| Available in following colours: | M/F red, Ford blue, Case red, John Deere green, Cat yellow, Landini blue, white, etc. |
| Fuel | Diesel | Paraffin | Petrol | Avgas | Jeta1 |
| Tank – 630 Liter Capacity | Mild steel 3mm | 304 2,5mm stainless steel | 304 2,5mm stainless steel | 304 2,5mm stainless steel | 304 2,5mm stainless steel |
| Status | Approved | Non-aviation | Non-aviation | Aviation approved | Aviation approved |
| Fire Extinguisher | Optional | Yes | Yes | Yes | Yes |
| Spare Wheel And Holder | Optional | Optional | Optional | Optional | Optional |
| Pump | Ad/dc/hand pump | Explotion proof ac/dc and handpump | Explotion proof ac/dc and handpump | Explotion proof ac/dc and handpump | Explotion proof ac/dc and handpump |
| Hoses | Standard petroleum
4m |
Standard 4m | Standard 4m | Aviation approved 4m | Aviation approved 4m |
| Filters | Dirt and water sep filter | Water absorption | Water abs | Parker velcon aquacon
Aviation filter |
Parker velcon aquacon aviation |
| Meters | 3 digit Jerrycar | Explosion proof 3 digit | Explosion proof 3 digit | Explosion proof 3 digit | Explosion proof 3 digit |
| Nozzles | Manuel or auto | Manuel or auto | Manuel or auto | Zvf25 aviation | Zvf 25 aviation |
| Maintenance Free Battery And Charger | Optional | Optional | Optional | Optional | Optional |
| Inspection Hatch | Optional | Optional | Optional | Optional required by some airports | Optional required by some airports |
| Bonding Reel | Optional | Yes | Yes | Yes | Yes |
| Breather | Standard or Donaldson breather or Gl3 Gilbarco | Donaldson | Donaldson | Donaldson | Donaldson |
| Drain Tap | No | Yes | Yes | Yes | Yes |
*Available as tank on frame to be fitted
*Available in various colours of choice
