Specifications
DRUM & WALL
-
MUST BE INSTALLED WITH PRESSURE REGULATOR-LUBRICATOR-PURIFIER
-
PNEUMATIC PUMPS SPECIALLY SUITABLE FOR OIL TRANSFER WITH LOW-MEDIUM
-
(SAE 15/50) AND ANTI-FREEZE FOR SHORT-MEDIUM DISTANCES (40-50M)
-
AIR PRESSURE MAY VARY BETWEEN A MIN OF 3.5 BAR AND A MAX OF 10 BAR
-
BUILT-IN FIXATION DRUM OF R2” AND M64X4 (ALSO CALLES BUNG ADAPTOR)
-
USING THE SUITABLE ACCESSORIES THESE PUMPS CAN BE HUNG UP ON THE WALL OR ASSEMBLED ON DRUMS, CONTAINERS AND MOBILE TROLLEY
OIL DELIVERY CAPACITY |
25L/MIN |
RATIO |
3:1 |
WORKING PRESSURE |
6-8 BAR |
AIR CONSUMPTION |
200L/MIN |
AIR INLET CONNECTION |
F ¼’’ G |
OIL OUTLET CONNECTION |
M ½’’ G |
NOISE LEVEL |
80DB |
SHANK DIAMETER |
42MM |
SHANK LENTH |
215MM (WALL)940MM (DRUM) |
WEIGHT |
3.78KG (WALL)5.35KG (DRUM) |
BOX VOLUME |
0.007 M^3 (WALL)0.016 M^3 (DRUM) |
