DRUM & WALL

• MUST BE INSTALLED WITH PRESSURE REGULATOR-LUBRICATOR-PURIFIER

• PNEUMATIC PUMPS SPECIALLY SUITABLE FOR OIL TRANSFER WITH LOW-MEDIUM

•  (SAE 15/50) AND ANTI-FREEZE FOR SHORT-MEDIUM DISTANCES (40-50M)

• AIR PRESSURE MAY VARY BETWEEN A MIN OF 3.5 BAR AND A MAX OF 10 BAR

• BUILT-IN FIXATION DRUM OF R2” AND M64X4 (ALSO CALLES BUNG ADAPTOR)

• USING THE SUITABLE ACCESSORIES THESE PUMPS CAN BE HUNG UP ON THE WALL OR ASSEMBLED ON DRUMS, CONTAINERS AND MOBILE TROLLEY

  OIL DELIVERY CAPACITY	25L/MIN
  RATIO	3:1
  WORKING PRESSURE	6-8 BAR
  AIR CONSUMPTION	200L/MIN
  AIR INLET CONNECTION	F ¼’’ G
  OIL OUTLET CONNECTION	M ½’’ G
  NOISE LEVEL	80DB
  SHANK DIAMETER	42MM
  SHANK LENTH	215MM (WALL) 940MM (DRUM)
  WEIGHT	3.78KG (WALL) 5.35KG (DRUM)
  BOX VOLUME	0.007 M^3 (WALL) 0.016 M^3 (DRUM)
